Features

• 4 x 100 Watts RMS @ 4 Ohm
• Compact Design for Smaller Installation Footprint
• Angled Terminals for show quality installations
• Full Range Class D Design
• Conformal Coated Printed Circuit Board for Marine and Motorcycle Applications
• DC, Short Circuit, Thermal and Overload Protection
• Diagnostic LEDs

• OUTPUT POWER @ 14.4V input
• RMS per channel at 4 Ohms 100 W x 4 CH
• RMS per channel at 2 Ohms 165 W x 4 CH
• RMS Bridged Mono at 4 Ohms 330 W x 2 CH
• RMS Mono at 1 Ohm N/A
• INPUT SENSITIVITY 200mV - 6.0V
• FREQUENCY RESPONSE 10Hz - 30KHz +/- 0.5dB
• THD LESS THAN 0.5%
• S/N RATIO > 91 dB
• CHANNEL SEPARATION > 70 dB
• DAMPING FACTOR @100Hz 4 ohm > 100
• CROSSOVER RANGE CH 3&4, CH 1&2
• High Pass, 12dB/Octave 20 Hz - 8K Hz
• Low Pass, 24dB/Octave 50 Hz - 8K Hz
• Band Pass N/A
• Variable Bass Boost No
• Wired remote bass control included No
• Phase Shift (0 - 180 degrees) No
• Fusing 1 x 60A
• Size (L x W x H) in 8.26 x 4.68 x2.04
