Earthquake EQ4000PXI 4 Band Equalizer with Aux and iPod Inputs B Stock
|
EQ4000PXI B
|
Retail Price: $170.00
Thunder AV Price: $68.95
You Save: $101.05 (59 %)
* Whole number only
Detailed Description
Factory B Stock, 30 Day Warranty!
Earthquake's line of equalizers do more than just alter your music. They give you 4 or 7 bands of equalization, subwoofer crossover, level controls and an extra audio input for a secondary source. You can control all this from the EQ-PXi with adjustable knobs. A few clicks and turns of the knobs and you can tailor all the EQ settings and level controls. Imagine the innovation involved in this one little half din unit. Extend your functionality.
* 4-band Graphic Equalizer
* 6-channel RCA Outputs (front/rear/subwoofer)
* Adjustable Master Volume Level Control
* Adjustable Subwoofer Level Control
* 3 Input Sources
* Gold Plated RCAs
* Easy Snap On Connector
* Red Led Background Display
* Input Gain (it Sets The Maximum Volume Level Achievable By The Front Controls)
CD Input
iPod Input
EQ4000PXi Specifications
Operating Voltage: 10.5---16VDC
Idle: 280 mA
Recommended fuse size: 1 Ampere
Input sources: 2 stereo RCA sources, 1 Phono source
Input sensitivity: Adjustable from 100mVrms up to 14 Vrms
Input impedance: Variable from 8 kOhm up to 10.2 Kohm
Output Impedance:
Sub channel: 510 Ohm
Front & Rear channels: 2.2 Kohm
Output Level:
Subwoofer channel: 5 Vrms @ 0.1% THD
Front & Rear channels: 4 Vrms @ 0.1% THD
T H D @ 3 Volts output: 0.05%
Frequency response: 15 - 34000Hz @ -3dB
Subwoofer frequency control range: 35 to 100Hz (@ -3db, 18dB/oct.)
Subwoofer upper cut off frequency: 100Hz
Channel separations: 68dB
Signal to noise ratio: 92dB
Center frequencies (in Hz): 50, 250, 275, 2200, 16000
Control Range: 30~40dB (12 O'clock is the Bypass position)
Dimensions(H x W x D): 1" x 7" x 4-1/4" (With Out Face Plate)
